Rear Toe Adjustment

1. Place vehicle in alignment mode. Alignment Mode Selection

Rear Toe Adjustment — figure 1

2. Rear Suspension Link Inner Nut (1) » Loosen
3. Rotate the rear suspension adjust link bolt (2) as necessary to achieve the required toe specification setting. Wheel Alignment Specifications
4. Rear Suspension Link Inner Nut (1) » Tighten — Fastener Specifications
5. Check the toe setting after tightening.
6. Re-adjust the toe setting if necessary.
